16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty

16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty
16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty

Large Image :  16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty Get Best Price

Product Details:
Place of Origin: China
Brand Name: XCMG
Certification: CE, ISO
Model Number: SQ16SK4Q
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiate
Packaging Details: Ro-Ro
Delivery Time: 20 days
Payment Terms: 30% deposit, balance before shipment
Supply Ability: 10000pcs/year
Detailed Product Description
Brand: XCMG Product Name: Telescopic Boom Crane
Max. Lifting Capacity: 16 Ton Max. Lifting Moment: 43.2 T.M
Max. Lifting Height: 20m Crane Weight: 6455 Kg
Oil Tank Capacity: 260L Rotation Angle: All Rotation
High Light:

telescoping boom crane

,

telescopic boom crane



16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min, Heavy Duty





Quick Details:



Name: Telescopic boom crane

Max. Lifting Capacity: 16 ton

Max. Lifting Moment: 43.2 T.M

Max. Oil Flow of Hydraulic System: 80 L/min

Max. Lifting Height: 20meters

Brand: XCMG

Crane Weight: 6455 kg

Oil Tank Capacity: 260 L





Description:



Telescopic crane is a easy to operate and more economical facility. The raise and down are driven by wire rope, easy to accurately control. The barycentre of the crane are far to the mounting point, beneficial for average the loading, the arm are more longer, with wide operating range.

Truck Loader Crane is a type of machine can carry heavy weights and transport them. The truck with crane mounted can load and unload the freight itself and don't need to employ another crane. The loader crane can freely route in 360 degrees, raise and extend, make the loading simple and economic. Compare to the mobile crane, truck loader cranes are more convenient and effective.

XCMG is the first company to develop newer design loader crane in China, shared more than 50% of the Chinese crane market for many recent years by the help of advanced design, good quality, attentive service and competitive price.

Together we define your needs and make the crane to match your request in every detail. The lifting capacity of our loader cranes spans from 2 to 25 ton and outreach over 20 meters.

Telescopic boom crane SQ16SK4Q is lifting capacity is 14tons, moment is 43.2 T.M.





Applications:



It can be applied on most common Commercial Truck-mounted Cranes. Range covers light to medium crane. With small mounting size and weight to save your payload, minimizing loading and unloading time, is the best choice of truck mounted crane facilities.

­



Specifications:



Model

SQ16SK4Q

Unit

Max Lifting Capacity

16000

kg

Max Lifting Moment

43.2

T.M

Recommend Power

41

kw

Max Oil Flow of Hydraulic System

80

L/min

Max Pressure of Hydraulic System

28

MPa

Oil Tank Capacity

260

L

Rotation Angle

All Rotation

Crane Weight

6455

kg

Installation Space

1400

mm

Choice of Chassis

BJ1317VNPJJ-S5 ;

NXG1310D3ZEX ;

DFL1311A3  ;





SQ16SK4Q Lifting capability diagram

Working radius(m)

2.7

5.6

8.5

11.5

14.5

18.5

Lifting capacity(kg)

16000

7000

4200

3200

 2200

1000





Dimension drawing


 16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 0


16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 1


 Optional parts:



1. Moment limited device
16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 2

  1. Remote control equipment
    16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 3
  2. Anti-overwind magnet valve
     16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 4
  3. High seat on column
    16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 5
  4. Work light
    16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 6
  5. Assisatant stabilizer leg
    16 Ton Telescopic Boom Truck Mounted Crane With 80 L/min , Heavy Duty 7



Stabilizer leg

Spread

Fixed

2179mm

Single extension

2256-3556mm

Double extension

2212-4752mm






Competitive Advantage:



1, Single cylinder synchronization guy cable technology make work efficiency more higher than before

2, Advanced development means make sure that the design is very reliable

3, The more symmetrical center design of pentagon & hexagon boom make it has bigger anti-bending capacity

4, Compact Hinge point design take up smaller space

5, The work is more safety after fitted with overwind alarm equipment

6, The integer lifting winch improved the work efficiency greatly and prolonged work life of hydraulic system

7, Float three-point bridge structure design can lower the accessional stress on the chassis when traveling

8, Self-designed & developed slewing machine with greater drive force can meet varied requirements of working situation

9, Anti-slewing impulse equipment that make vehicle running safely.
