Product Details:
Payment & Shipping Terms:
|
| Model: | SQ8SK3Q | Maximum Lifting Mass (Kg): | 8000 |
|---|---|---|---|
| Model Of Engine: | WD615.62 | Outrigger Span （mm）: | 2280~5580 |
| High Light: | Emergency Tow Truck,Breakdown Recovery Truck |
||
Product description:
1. Structural pieces with 690MPa high-strength steel plate welding, high strength, good toughness, light weight.
2. The use of advanced three-dimensional design and stress analysis to ensure product reliability.
3. Rotary mechanism using hydraulic mechanical double brake, to ensure the operation and driving safety.
4. Winning mechanism using mature hydraulic winch structure of small noise, high efficiency, good reliability.
5. Suspension and contraction of the three-stage cylinder + cable with telescopic form, with the ability to carry the leading domestic, cylinder part of the 100%, rigging part of 2 /
6. Work range, wide range of applications.
Products with car seat control, operation field of vision better, more secure operation.
|
Chassis specification |
Model | ZZ1161M5011W |
|
Wheelbase (mm) |
5000 | |
|
Model of engine |
WD615.62 | |
|
Power of engine (Kw/Ps) |
196/266 | |
| The vehicle shape | Long(mm) | 9530 |
|
Width(mm) |
2450 | |
|
High(mm) |
3600 | |
| Crane | Model | SQ8SK3Q |
|
Maximum lifting mass (Kg) |
8000 | |
|
Outrigger span (mm) |
2280~5580 | |
|
Maximum operating radius (mm) |
11500 | |
|
Hydraulic system rated pressure (MPa) |
27 | |
|
Rotation angle (°) |
360° | |
| Platform |
Platform platform Dimensions (L×W)mm |
6000×2450 |
|
Platform Stretch Travel (mm) |
3410 | |
|
Platform maximum packing capacity (Kg) |
5000 | |
|
And the minimum angle of the ground (°) |
8 | |
|
Winch rated tension (KN) |
50 | |
| Corbel |
Lifting lift mass (Kg) |
5000~2500 |
|
Maximum tow mass (Kg) |
12000 | |
|
Maximum effective length of arm (mm) |
2050 | |
|
Stretch travel (mm) |
1620 |
F A Q
Q: Are you a trading company?
A: No, we have our own factory, factory+trading company.
Q: How is your warranty?
A: We provide 12 months warranty for our products.
Q:If I don’t know how to install, what should I do?
A: Don’t worry about that, we have professional engineers help you.
Q: How is your after-sale service?
A: 24 hours and 7days service.
