Special Purpose Vehicles Self Dump Trucks , Waste Collection Vehicles XZJ5160ZLJ

Special Purpose Vehicles Self Dump Trucks , Waste Collection Vehicles XZJ5160ZLJ
Special Purpose Vehicles Self Dump Trucks , Waste Collection Vehicles XZJ5160ZLJ

Large Image :  Special Purpose Vehicles Self Dump Trucks , Waste Collection Vehicles XZJ5160ZLJ Get Best Price

Product Details:
Place of Origin: China
Brand Name: XCMG
Certification: CE ISO
Model Number: XZJ5160ZLJ
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiate
Packaging Details: Ro-Ro
Delivery Time: 30-50 days
Payment Terms: 30% deposit, balance before shipment
Supply Ability: 11000pcs/year
Detailed Product Description
Vehicle Model: XZJ5160ZLJ Chassis Model: EQ1168KJ
Maximum Total Mass: 16000kg Kerb Mass: 7805kg
Tilt Angle: ≥48° Wheelbase: 4500mmm
Carriage Volume: 17L
High Light:

road wrecker truck

,

rescue tow truck



Special Purpose Vehicles Self Dump Trucks, Waste Collection Vehicles XZJ5160ZLJ





Application:



Dumping trucks are special purpose vehicles to collect and forward the refuse conveniently, avoid any leakage pollute  the  road  will  transport, ideally utilities for city sanitation.





Description:



Dumping trucks are special purpose vehicles to collect and forward the refuse conveniently, avoid any leakage  pollute  the  road  will  transport, ideally utilities for city sanitation. They  are  two types of the carriages,  top opening carriage and sealed carriage. top opening carriage garbage trucks are mainly designed for bulk refuse loading, also can support the large vertical compressor. Sealed carriage garbage trucks are mainly for support small-middle size compressor, as forward vehicles, very important ring of refuse treatment system.





Specification:



Vehicle Model

XZJ5160ZLJ

Chassis model

EQ1168KJ

Maximum total mass

16000kg

Kerb mass

7805kg

Rated pay load

8000kg

Carriage volume

17L

Tilt angle

≥48°

Max. pressure of hydraulic system

20Mpa

Size(length×width×height)

7850*2480*2960mmm

Wheelbase

4500mmm

Front overhang / rear overhang

1205/2145mm

Approach angle

25/l9°

dump time

≤60s





Competitive Advantage:



  1. Use the technology and processing experience of internal & external for reference, designing according to china' actual conditions, is an highly adapta bility machine.
  2. Select and use famous brand chassis, meet emission standards,  saving energy and  miore economic.
  3. Adopt close body, sealed backdoor and big volume sewage tank to avoid leakage and pollution on the way.
  4. Adopt dumping type of unloading garbage, simple in structure and dumping garbage in rapid speed.
  5. Adopt air controlled + hand operated operation type to control container backdoor and overturning body, that reduce the intensity of labour and improve working environment.
  6. Adopt explosion valve,  hydraulic lock and safety rod to ensure that the operation is safely and reliable.
