Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things

Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things
Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things

Large Image :  Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things Get Best Price

Product Details:
Place of Origin: China
Brand Name: XCMG
Certification: CE, ISO
Model Number: SQ10ZK3Q
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiate
Packaging Details: Ro-Ro
Delivery Time: 20 days
Payment Terms: 30% deposit, balance before shipment
Supply Ability: 10000pcs/year
Detailed Product Description
Brand: XCMG Product Name: Knuckle Boom Truck Mounted Crane
Max. Lifting Capacity: 10 Ton Max. Lifting Moment: 20 T.m
Max. Lifting Height: 13000mm Crane Weight: 3477 Kg
Oil Tank Capacity: 160L Extension Length: 9755mm
High Light:

folding boom crane

,

knuckle boom crane



Durable XCMG Knuckle Boom Truck Mounted Crane 20 t.m For Lifting Heavy Things





Quick Details:



Name: Folding boom truck crane, Knuckled boom crane, Knuckle boom truck mounted crane

Max. Lifting Capacity: 10 ton

Max. Lifting Moment: 20 t.m

Max. Oil Flow of Hydraulic System: 40 L/min

Max. Lifting height: 13meters

Brand: XCMG

Crane Weight: 3477 kg

Oil Tank Capacity: 160 L





Description:



Knuckle boom crane, help you loading goods on your truck. The crane will fold to compact size after working and will not affect the space of the carriage. The arms are driven by hydraulic, move fast, more effective. The arms can easy to reach narrow spaces like inside the workshop. More accessories like fork, grab bucket, can be attached for different goods loading.

Truck Loader Crane is a type of machine can carry heavy weights and transport them. The truck with crane mounted can load and unload the freight itself and don't need to employ another crane. The loader crane can freely route in 360 degrees, raise and extend, make the loading simple and economic. Compare to the mobile crane, truck loader cranes are more convenient and effective.

XCMG is the first company to develop newer design loader crane in China, shared more than 50% of the Chinese crane market for many recent years by the help of advanced design, good quality, attentive service and competitive price.

Together we define your needs and make the crane to match your request in every detail. The lifting capacity of our loader cranes spans from 1 to 25 ton and outreach over 26 meters.

Knuckle boom crane SQ10ZK3Q is lifting capacity is 10tons, moment is 20T.M.





Applications:



It can be applied on most common Commercial Truck-mounted Cranes. Range covers light to medium crane. With small mounting size and weight to save your payload, minimizing loading and unloading time, is the best choice of truck mounted crane facilities.

­



Specifications:



Model

SQ10ZK3Q

Unit

Max. Lifting Moment

20

t.m

Max. Lifting Capacity

10000

kg

Recommend Power Needed At Recommend Oil Flow

28

kw

Max. Oil Flow of Hydraulic System

40

L/min

Rated Pressure Of Hydraulic System

28

MPa

Oil Tank Capacity

160

L

Rotation Angle

(360°) All Rotation

.

Crane Weight

3477

kg

Installation Space

1150

mm

Choice of Chassis

DFL1250A9 ;

CA1240PK2L7T4EA81 ;

HFC1202KR1K3 ;

EQ5201GFJ6 ;

CA1200PK2L7T3EA80 ;

BJ1317VNPJJ-S5 ;

BJ5253ZKPJJ ;

CA1253P7K2L11T1E  ;

EQ1252GFJ ;

DFL1253AX ;





SQ10ZK3Q Lifting capability diagram

Working radius (m)

2

4.17

5.99

7.78

9.75

Lifting capacity (kg)

10000

 4600

3050

2280

1700





Dimension Drawing:



Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things 0

Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things 1

Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things 2





  Optional parts:



 1.Remote control equipment





Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things 3



2.Moment limited valve



Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things 4



3.High seat on column



Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things 5



4.JIB



Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things 6



5.Assisatant stabilizer leg



Durable XCMG 10 ton Knuckle Boom Truck Mounted Crane For Lifting Heavy Things 7



Stabilizer leg

Spread

Fixed

2179mm

Single extension

2256-3556mm

Double extension

2212-4752mm





Competitive Advantage:



1, Advanced development & analysis means make sure design is very reliable

2, Higher lifting capacity with tour connected bar mechanism

3, Flange telescopic boom coupling technology

4, Self-designed & developed slewing machine with greater drive force can meet varied requirements of working situation

5, The more symmetrical center design of hexagon boom make it has bigger anti-bending capacity

6, Float three-point bridge structure design can lower the accessional stress on the chassis frame when traveling
