| Model: | XZJ5060JGK | Chassis Model: | JX1060TSG23 |
|---|---|---|---|
| Engine Model: | JX493ZLQ3 | Engine Power: | 85kw |
| High Light: | rescue tow truck,road wrecker truck |
||
Parameter:
|
Vehicle Model |
XZJ5060JGK |
|---|---|
| Max Operating Height | 17.3m |
| Max Operating Radius | 8.3m |
| Rated Load of Platform | 200Kg |
| Slewing Angle | ±360° |
| Max Operating Radius on Maximum Operating Height | 2.7m |
| Max Operating Height on Maximum Operating Radius | 9.6m |
| Max Lifting Capacity | 2000Kg |
| Max Lifting Height | 9.2m |
| Dimension in Driving( L × W × H) | 7660×2000×2920(mm) |
| Chassis Model | JX1060TSG23 |
| Engine Model | JX493ZLQ3 |
| Engine Power | 85kw |
| Passengers |
2+3 |
Originally imported Germany Hawe solenoid valve (main control valve), proportional valve, and proportional handle.
Electro-hydraulic proportional control, stepless speed regulation, and superior operational performance.
There is elevation angle limit device for the upper arm, which can avoid danger.
The emergency pump is available.
The imported key parts has high reliability, good performance and long service life.
The work platform is mounted at the rear part, which is convenient to enter or exit the cab; and it also reduces the gravity of the whole machine and improves travel performance.
The work platform can slewing ±90°, which is convenient for the aerial work.
Convenient one button extension/withdrawal function.
