Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE

Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE
Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE

Large Image :  Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE Get Best Price

Product Details:
Place of Origin: China
Brand Name: XCMG
Certification: CE, ISO
Model Number: SQ6.3ZK2
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiate
Packaging Details: Ro-Ro
Delivery Time: 20 days
Payment Terms: 30% deposit, balance before shipment
Supply Ability: 10000pcs/year
Detailed Product Description
Name: Folding Boom Truck Crane Max. Lifting Capacity: 6300 Kg
Max. Lifting Moment: 13.23 T.m Max. Lifting Height: 11m
Crane Weight: 2152 Kg Rotation Angle: (360°)All Rotation
High Light:

Knuckleboom Crane

,

Folding Truck Crane



Durable Wire Rope Articulated Boom Crane For Coal Mining Engineering, With ISO CE





Quick Details:



Brand: XCMG

Name: Folding boom truck crane, Lorry mounted crane

Max. Lifting Capacity: 6300 kg

Max. Lifting Moment: 13.23 t.m

Max. Oil Flow of Hydraulic System: 25 L/min

Max. Lifting Height:11meters

Crane Weight: 2152 kg

Oil Tank Capacity: 90 L





Description:



Knuckle boom crane, help you loading goods on your truck. The crane will fold to compact size after working and will not affect the space of the carriage. The arms are driven by hydraulic, move fast, more effective. The arms can easy to reach narrow spaces like inside the workshop. More accessories like fork, grab bucket, can be attached for different goods loading.

Truck Loader Crane is a type of machine can carry heavy weights and transport them. The truck with crane mounted can load and unload the freight itself and don't need to employ another crane. The loader crane can freely route in 360 degrees, raise and extend, make the loading simple and economic. Compare to the mobile crane, truck loader cranes are more convenient and effective.


XCMG is the first company to develop newer design loader crane in China, shared more than 50% of the Chinese crane market for many recent years by the help of advanced design, good quality, attentive service and competitive price.

Together we define your needs and make the crane to match your request in every detail. The lifting capacity of our loader cranes spans from 1 to 25 ton and outreach over 26 meters.

Knuckle boom crane SQ6.3ZK2 is used for lifting 6.3tons, moment is 13.23T.M.



 Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 0

Applications:



It can be applied on most common Commercial Truck-mounted Cranes. Range covers light to medium crane. With small mounting size and weight to save your payload, minimizing loading and unloading time, is the best choice of truck mounted crane facilities.

­



Specifications:



Model

SQ6.3ZK2

Unit

Max. Lifting Moment

13.23

t.m

Max. Lifting Capacity

6300

kg

Recommend Power Needed At Recommend Oil Flow

18

kw

Max. Oil Flow of Hydraulic System

25

L/min

Rated Pressure Of Hydraulic System

28

MPa

Oil Tank Capacity

90

L

Rotation Angle

(360°)All Rotation

°

Crane Weight

2152

kg

Installation Space

1050

mm

Choice of Chassis

CA1163P7K2L3E  ;CA1176PK2L9T3A95  CA1170PK2L7T3EA80 ; CA1140PK2L3EA80   ; DFL1140B ;EQ1126KJ1 ;HFC1132KR1K3 ;

HFC1202KR1K3 ;EQ1141NBJ2 ;

EQ5161GFJ7 ;BJ1317VNPJJ-S5 ;EQ5201GFJ6 ;LZ1160LCMT  ;

DFL1250A9 ;BJ5317ZNPJJ-S ;HN1310P29D6M3J  ;

NXG1160D3ZAL1X ;



SQ6.3ZK2 Lifting capability diagram

Working radius (m)

2.1

4.44

6.2

8.01

Lifting capacity (kg)

6300

2700

1700

1200





Dimension Drawing:



Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 1

Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 2

Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 3





 Optional parts:





 1.Remote control equipment





Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 4



2.Moment limited valve



Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 5



3.High seat on column



Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 6



4.JIB



Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 7



5.Assisatant stabilizer leg



Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 8



Stabilizer leg

Spread

Fixed

2179mm

Single extension

2256-3556mm

Double extension

2212-4752mm



Competitive Price Wire Rope Articulated Boom Crane For Coal Mining Engineering, WITH ISO CE 9

Competitive Advantage:



1, Advanced development & analysis means make sure design is very reliable

2, Higher lifting capacity with tour connected bar mechanism

3, Flange telescopic boom coupling technology

4, Self-designed & developed slewing machine with greater drive force can meet varied requirements of

working situation

5, The more symmetrical center design of hexagon boom make it has bigger anti-bending capacity

6, Float three-point bridge structure design can lower the accessional stress on the chassis frame when

traveling
